| مكان المنشأ: | الصين |
| اسم العلامة التجارية: | MIROC |
| إصدار الشهادات: | ISO |
| رقم الموديل: | PR54R RC Drill Drill Drill |
| الحد الأدنى لكمية: | 1 |
|---|---|
| وقت التسليم: | 20-30 |
| القدرة على العرض: | 3000 |
| عملية التصنيع: | تزوير | مادة: | سبيكة الصلب |
|---|---|---|---|
| ميزة: | أداء عالي | لون: | حسب الطلب |
| اسم الأجزاء: | مثقاب DTH | الاستخدام: | ثقب drlling |
| إبراز: | RC hammer drill bit for DTH hammer,reverse circulation drill bit for rock drilling,PR54R RC hammer bit with warranty,reverse circulation drill bit for rock drilling,PR54R RC hammer bit with warranty |
||
| Attribute | Value |
|---|---|
| Manufacturing Process | Forging |
| Material | Alloy Steel |
| Advantage | High Performance |
| Color | Per Request |
| Parts Name | DTH Drill Bits |
| Usage | Hole Drilling |
RC series reverse circulation DTH Hammer is mainly used for deep exploration drilling and stope ore grade control. This reverse circulation drill bits are widely used in the following application fields:
Specifically designed to work with RC Hammers.
Other sizes available upon customer request. Customization available.
| Diameter mm | Diameter inch | No x Button diameter | Button angle | Flushing holes | Shroud Dia mm | Weight (kg) | Part No | |
|---|---|---|---|---|---|---|---|---|
| 136 | 5 3/8 | 8 x 16mm | 6x16+3x14 | 35 | 2 | 134 | 19.0 | PR54-136 |
| 140 | 5 1/2 | 8 x 16mm | 6x16+3x14 | 35 | 2 | 138 | 19.3 | PR54-140 |
| 143 | 5 5/8 | 8 x 16mm | 6x16+3x14 | 35 | 2 | 141 | 19.5 | PR54-143 |
| 146 | 5 3/4 | 8 x 16mm | 6x16+3x14 | 35 | 2 | 144 | 19.6 | PR54-146 |
